Automatic Chicken Waterer Made From 5 Gallon Bucket

  1. FutureChickenMan
    What you'll need
    1 Toilet fill valve; I used a fluid master $10
    1 Toilet supply line $3 (make sure it has 1/2" female pipe thread connector.
    1 1/2" male pipe thread by 3/4" female garden hose adapter $3
    1 Light socket with switch $3
    1 9' 2 prong extension cord $2
    All other parts used bucket, nuts, bolts, washers, light bulb, piece of metal and zip ties, I had in the shop.
    Take the bucket and make 5 marks 9" up from the bottom of the bucket as evenly spaced as possible. ***After a couple months of testing, I've found that the 9" from the bottom hole location is a bit low and can be subject to overflowing. That said, make the hole location 10 inches or higher from the bottom. This gives more adjustment variant for the valve.*** It's important that the measurement/marks are as level as possible. Once marked, get a 2 1/2" hole saw (it's a drill bit about $8 if you don't have one) loaded in to your drill. Put the pilot bit on the marks you made and drill out the holes one by one being careful to keep the pilot bit on your mark. These will be the drinking holes for the chickies.

    Get the toilet fill valve out. With a hack saw, cut off about 1" of the threaded rod on the bottom of the valve. This will allow the valve to sit lower in the bucket. Try to cut the threaded part as straight as possible. Next thread on the supply hose. Next drill a hole for the pipe to garden hose adapter, you'll need to dry fit this so you can see how much slack or lack there of is in the toilet supply line. This will help you locate where the hole needs to be for the fitting. Toilet supply lines are hard to find in any other length than 12". Once the hole is drilled, use some teflon tape on the 1/2" male pipe threads and screw it in to the hole you just drilled in the bucket. Attach the loose end of the supply hose to the pipe fitting.
    With the valve in the bucket, stand it up as vertical as possible. Eyeball or measure if you wish for the metal bracket. Bend one end of the metal bracket down and one end up (like a flattened out "S"). Use zip ties to connect one end of the metal bracket to the upper part of the shaft on the fill valve. Be careful that the float (the black cylinder in this case) does not hit the metal bracket or drag on anything. This float turns the water on and off and needs to move freely.
    Bolt the other end of the bracket to the bucket. Install optional light socket and wiring.
    Once it's all assembled, take it out to the coop. The bucket needs to be placed on level ground, very important. Once placed on a hard level surface, connect the garden hose and turn on the water, slowly. The bucket will begin to fill. With the lid off, adjust the valve (see manual for the valve) float level. Ideally you will get the water up to the very bottom of the holes. You will need to watch the holes to find out which one is lowest as this one will be the first to over flow. This hole is the one you need to adjust the float to. Once adjusted, the valve will come on when the water level decreases (gets consumed by the chickies). In my test, I removed 12 ounces of water then the valve came on. This won't work so well when it gets below freezing as your garden hose will freeze (I'm working on a modification for this)
    Here's what it looks like filled up with water.


    Share This Article


To make a comment simply sign up and become a member!
  1. MizPriz
    Sounds cool. Just wish I could see the photos, since I am a visual learner.
  2. venymae
    None of the pictures work for this anymore :(
  3. sprouticus
    i used a similar setup, except i drilled a hole in the bottom of my bucket and hooked my braided line up to that directly. with the gasket that the toilet kit came with i don't have any leaks, and this eliminated the need for a bracket of any kind. my waterer is in a hole, and sits on a base made from the bottom 2 inches of another bucket turned upside down. this allows the plumbing to not get flattened by the weight of the full water bucket. I also used heat trace wire, which for you southerners is a wire that uses 26 watts of electricity for every meter when its really cold out, and less power if its not too cold. It heats up to a maximum of 32 degrees celcius i think, so no fire hazard. i wrapped this wire around the bucket a few times, and also ran it parrallel to my garden hose and then wrapped it all in foam insulation. with the couple of feet left over i just put some of the end in the wood chips to provide some warmth, but i think i may cut that section off to save on power. I am also going to wire the whole setup into my timer for my light i think, instead of being on all the time (when its cold out, cause this stuff turns itself off if it is warm outside). My water is above room temperature...even when its below freezing outside, and will never freeze. I have ducks, and the tend to wash their bills in their water, and my only issue will be cleaning this contraption out every now and then, and i'm also worried about algae in the summer. I'm toying with the idea of adding either a little pool chorine, some apple cider vinager, or perhaps even an algae heater from my fishtank into this bucket in the summer time to control the algae, and i suppose a shop vac once a month or so will remove the mud and dirt from the bottom. My coop is only 4 feet high and i hate having to bend over to collect the dishes to feed/water them everyday, so i also built a feeder fed from a large hopper so i can feed them from the outside every week or so. Basically the only work i have now is to collect the eggs in the morning, put them in the coop at night, and change their wood shavings/ shop vac the waterer every month or so.
  4. bruceha2000
    I'm with OmeletMan. An ungrounded open socket?? Electricity and water don't mix well. WAY too much possibility of having electrocuted chickens or humans.
  5. idahochick
    After trying several different set ups wih too many overflow issues I will get my sweet and multi-talented hubby to make us one for our growing tribe. Thanks for the great pictures.
  6. OmeletMan
    Great waterer. I dont like the light bulb. Why not just get a cheap aquarium heater?
  7. AustinH
    Thanks for posting this lots of help
  8. FireTigeris
    I wonder with a large enough tray/feed pan if you could cut a hole for the bucket to sit in and have a 'pan' water style, then I could build a ramp to the pan and have the holes smaller so chicks can use it also.
  9. blackwolffarm
    I like this waterer. I will have about 50 chickens, I will build everything. I will make at least 5 of these. I am way out in the country so will have to do all. Thanks, Kerry
  10. strutncrow
    thats neat ill have to post my set up its a gravity waterer w/ chicken nipples on the ends.i like the hose being connected
  11. jdeoliveira74
    what is the light for is it to keep the water from freezing in winter??
