Coop Windows

Discussion in 'Coop & Run - Design, Construction, & Maintenance' started by SandyK, Aug 19, 2010.

  1. SandyK

    SandyK Chillin' With My Peeps

    388
    3
    124
    Jul 8, 2009
    Eldersburg, Maryland
    For those who have bought their coop windows and don't want the hardware cloth showing on the outside, what did you do on the inside to secure the window from animals coming in the coop? I really don't want the hardware cloth showing on the outside.

  2. elmo

    elmo Chillin' With My Peeps

    4,852
    33
    249
    May 23, 2009
    DFW
    Buy the black vinyl coated hardware cloth, or paint the regular galvanized hardware cloth black. When it's black, you can hardly see it.

  3. SandyK

    SandyK Chillin' With My Peeps

    388
    3
    124
    Jul 8, 2009
    Eldersburg, Maryland
    Thanks Elmo, I didn't know they made it in black. Good idea.

  4. elmo

    elmo Chillin' With My Peeps

    4,852
    33
    249
    May 23, 2009
    DFW
  5. Pineywoods Peepers

    Pineywoods Peepers Certified Poultry Accruer

    I wanted to leave the screens on my coop windows to keep bugs out of the chicken house, but I also wanted to be able to access them easily to clean them when they got cruddy, so I didn't want to screw hardware cloth directly into the window trim. And I couldn't put the hardware cloth on the inside because I needed to be able to access the windows to open and close them. But I knew I wanted (and needed) hardware cloth to keep out predators.

    Here's the solution we came up with. My husband built a frame that would fit over the bottom half of window, and we attached the hardware cloth to that frame. We then took the hardware cloth frame and attached it with hinges to the interior frame of the windows and put a latch the opposite side for secure closure. I probably haven't explained that very well, so I'm including a picture:

    [​IMG]

    Screen when it is closed.

    [​IMG]

    Screen when it is open.

    After I took these pictures we screwed a small 1X2 into the window frame behind the top of the hardware cloth screen to prevent any critters that tear through the regular window screen from squeezing into the coop.

    We had thought about attaching these screens to the exterior of the windows, but we were concerned about moisture trapped between the screen and the trim deteriorating the wood.

    Rachel

    PS When I say "we" did something it really means "he" did it. [​IMG] I'm more of an "idea man".

    Last edited by a moderator: Aug 20, 2010
    1 person likes this.
  6. SandyK

    SandyK Chillin' With My Peeps

    388
    3
    124
    Jul 8, 2009
    Eldersburg, Maryland
    Thanks so much Rachael, pictures were great. DH and I were discussing this last night and it is exactly what we came up with also. I wanted to leave the window screens in also, but just know that if a critter attempts to get in, they are history. Been there on another coop years ago.

  7. Pineywoods Peepers

    Pineywoods Peepers Certified Poultry Accruer

    My husband used a Kreg pocket screw jig to make the frames. He loves using it, and it makes for a very sturdy frame too.

    Yeah, I figure my screens will eventually bite it when a predator attempts to get in, but at least it'll keep the skeeters out for now....

    Rachel

    Last edited by a moderator: Aug 20, 2010
  8. moetrout

    moetrout Chillin' With My Peeps

    842
    32
    153
    May 5, 2010
    Milan, MI
    When I get to that point I plan on putting my hardware cloth between the stud wall and the siding. This way it is outside, but not screwed to the trim and you can still get to the window inside and open/close or remove the screen.

  9. jomercer

    jomercer Chillin' With My Peeps

    Very nice. Did he already have the Kreg setup, or was that his good excuse to buy one?

  10. Pineywoods Peepers

    Pineywoods Peepers Certified Poultry Accruer

    LOL

    He had been wanting one for a while (like a year or two, but I kept finding excuses not for him to spend the $), but he had to buy one a couple of weeks before when a friend of ours was going to pay him to build cabinet doors for some open shelves. I have to say it came in very handy on the chicken house - he built the 4 window screens and the screen door for the coop with his new jig.

    He's quite enamored with that little doohickey. I wish I'd let him buy it sooner.

    Rachel
