patimekillers Chicken grazing pen

Discussion in 'Coop & Run - Design, Construction, & Maintenance' started by patimekiller, Jun 13, 2010.

  1. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    Here is my chicken grazers feel free to ask questions and I will keep posting things about them if I don't get it all down in one day. I have 2 pens built the same. Here is the verry first one I built it if 4x8x2 ft tall.
    [​IMG]
    it had wheels on the back but I took them off for my new pens.
    Here are the new larger pens they are 2 ft tall 8ft wide 14 ft long
    [​IMG]
    I have 50 Cornish x rocks in each pen they have lots of room. The pen is built out of 2x4 full size rough cut and the frame alone is close to 300 lbs. The pen has wheels on all 4 corners that lift / cam the pen up for transport and set it down to keep varmits out. the lift hight is 3-4 in. That allows for any bumps in the yard. The wheels are 8-13 inches in dia lawn mower wheels. They have metal bearings in them. One set I had to buy brand new @ 12.00 a wheel. One set I paid a buck a wheel to a guy who was junking a high wheel mower. The other 2 sets I got for free. [​IMG]
    [​IMG]
    the cam bracket is 5 inches of3/4 rigid pipe welded to hold the wheel and a handle the attatchment point on the pen is a 5/8 bolt 10 in long( these came from local electric co the use them and you may be able to get some from them ) or 5/8 allthread. The handles pin in the up right position so they dant slam down on chicks while moving.
    [​IMG]
    one person can lift and move roughly 400 lbs of pen in less than 5 min. My waterer is just a bell waterer hooked up to a five gallon gravity feed[​IMG]
    the water is suspended off the ground by a few in when pen is down. My feeder is a 30 lb feeder that goes on a pully system to get it under the roof so it stays dry.[​IMG]
    [​IMG]
    the pipe has 1 half inch nut to space it down so the ring can slide out
    [​IMG]
    the feeder also is a few in off the ground.
    [​IMG]
    there are a few things I would change so if you would like to know I will post what I think needs changed later my batt on my phone isn't gonna last much longer. Last but not least Josie our Jack Russel is checking on her babys
    [​IMG]

    Last edited: Jun 14, 2010
  2. redhen

    redhen Kiss My Grits... Premium Member

    35,111
    134
    458
    May 19, 2008
    Western MA
    Very good job!

  3. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    Thanks I have to give credit where it due

    father in law -thanks for the wood and help assembling and putting up with me
    wife- she came up with the grazed chicken idea from some where she also kind of let me go on design except roof to sun light ratio I wanted more roof she said more light.......


    They got more light

  4. j3707

    j3707 Chillin' With My Peeps

    117
    0
    109
    Dec 29, 2009
    Pacific Northwest
    Looks great - some nice design features. Tell your wife to get you a cold one!

  5. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    She needed the cold one after putting up with me and her dad on this project;)

  6. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    Bump. [​IMG]

  7. flgardengirl

    flgardengirl Chillin' With My Peeps

    4,427
    64
    246
    Dec 2, 2009
    Sunny side up :)
    Very smart design and waterer setup. Bet the chickens love it with all that fresh green grass continuously available. [​IMG]

  8. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    Thanks for the comments by all feel free to make something like this for your self I'll get more detailed photoes if you ask

  9. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    Thanks for the comments by all feel free to make something like this for your self I'll get more detailed photoes if you ask

  10. patimekiller

    patimekiller Out Of The Brooder

    76
    1
    41
    Jun 5, 2010
    Nw pennsylvania
    Any one else have trouble with these 30 lb drum feeders with the feed sticking and not falling.
