    Hello and Welcome to TNDadx4's Lessons Learned Chicken Page!

    [​IMG]


    We are new to raising chickens as we were just given 6 Araucana (Easter Egg) chickens. It is a personal goal of mine to try to live as self-sufficient and as simply as possible. I hope by sharing some information that others will be helped by what I've learned.
    [​IMG]

    I am also going to beposting pictures of the chicken tractor that the kids and I built over the course of a few weekends.
    The picture to the left is the very first eggs that we got from our new hens. We brought them home late (about 10PM) one night and didn't expect any eggs for a few days while they got adjusted, but they surprised us the next day with an egg from each of them.


    n.Speaking of eggs, that was a lesso


    Lesson One - Egg Schedule: I thought that chickens laid their eggs at night when they went back into the hen house to roost, etc. I've since learned that most eggs are laid before 10:00 AM, although I've found them all throughout the day. I've since learned that it's best to check for eggs at 10:00AM, 1:00PM and then at 5:00PM, just to be on the safe side.

    Lesson Two - Sick Chicken?: It was really warn the other day and we put a tarp over the top of the chicken run to provide then with some shade. We also made sure that their waterer was kept full of fresh water . While we were watching them, the strangest thing happened, one of them laid down with her mouth open and laid on her side for a bit. A little while later, another did the same. We started to get worried thinking that the chickens were sick, had heat exhaustion or something and then learned through talking with a friend that has chickens that everything that we saw was normal. It turns out, when it's warm outside, our hens will look for a place and scratch down until they reach nice, fine dirt. They then flop onto their backs, close their eyes and just roll around. This is how they keep clean! What a very cool and interesting thing to learn!

    [​IMG]



    More to come, so check back soon!




    [​IMG] [​IMG]



    [​IMG] [​IMG]





    Our Chicken Tractor


    In building our chicken tractor, I looked at a lot of designs, but we didn't use any plans. I took features that I liked some several and came up with a design in my mind as to how I wanted it to be. Below, you'll see some of the construction as well as finished photos.

    The Chicken Tractor (Construction Phase)

    [​IMG]
    Here, we laid out the 2x4's and are building the frame. The whole tractor is 12' long x 4' high x 4' wide

    [​IMG]
    In this picture, the girls are working on the top half of the sides of the run, which are covered in chicken wire. The bottom half is surrounded with 1/2" hardware cloth to make a good predator barrier.

    [​IMG]
    Here, the boys are working on cutting the wood for the back of the nest boxes and finishing the side entry door for the run.
    The Chicken Tractor (Completed)
    [​IMG]

    Here is a view looking down the run back towards the hen house. The hen house is raised for several reasons.



      • To give the hens more room in the run
      • To give them a shaded area outside of the hen house where we can hang their food and water to keep it out of the rain and sun
      • To make it harder for predators to get to them.
    Here, you can also see that the hardware cloth on the bottom 2' is attached to the 2x4's using fender washers and screws making it easier to remove or tighten as necessary.
    The chicken wire on the top 2' is attached with both washers and screws as well as poultry staples because it's not as sturdy.

    [​IMG] This is a different view of the fron looking down the run towards to hen house. You can also see here that we installed hooks to hang the feeder and waterer rather than keeping them on bricks. Also in this picture, also it's hard to see is a perch for the chickens to roost on. The perch goes under the walkway and acts to keep the edge of the bottom a few inches off the ground so it doesn't get caught when we more it.
    [​IMG]
    Here is a view of the side of the tractor with it's new wheels. They make it a whole lot easier to move rather than dragging a heavy frame on the ground.
    You can also see the 15" x 15" door in the side of the hen house. this is for ventilation and to make cleanout easier. What you can't see is that there is stick-on tile on the main part of the floor inside the coop to again help with cleanout and to keep odors from getting into the wood.

    [​IMG]This is a view from the back, you can see the rear and front ventilation windows. Also you can see the hinged cover for the nest boxes. By having the next boxes outside the tractor, we can collect eggs without walking in any chicken poop or without worrying about the chickens getting out.
    [​IMG] Here is the access/cleanout/ventilation door in the side.
    [​IMG]This interior picture was taken through the access/cleanout/ventilation door in the side. It shows the upper roost, rear window (with hardware cloth) and a bit of the nest boxes.
    [​IMG]Here is a better view of the same area as the previous picture. This one shows the nest boxes better. We have two; one larger one on the left and one smaller one on the right.


    In building our next coop, we would take certain lessons learned in the construction of this one. These include:


      • Using shorter nails to nail the 2x4's together. At the time, we used 3" nails for most of the frame work and had some splitting of wood as well as some nail tips that came through the other side that we now have to clip off.
      • I would put the nest boxes on one of the sides rather than on the back of the coop. It was done for ease when building, but I didn't take into account the positions of the roosts inside, so we had to add a high roost and a short roost. Instead, I wanted to give them enough room for all 6 to roost together on the same perch. Right now, only 5 can fit on each. Sometimes they split up and other times, 5 take the top and 1 gets the bottom.
      • This is a chicken tractor, but a HEAVY chicken tractor. It takes two grown men to move it. We plan on putting at least two wheels on it to see if that helps with the portability.
      • The original design did not account for the roost space issue that I discussed above, so we had to raise the roof to add headroom and vents for the girls. This was very hard after the fact and added to the weight because more framing was used with what we had left.
      • The roof was built without rafters (to keep the weight down), but it is not as strong as a regular roof.




    [​IMG]


    Share This Article

Comments

To make a comment simply sign up and become a member!
  1. DesigningLife
    Wow, great job! It reminds me a bit of mine, although I see features on yours I would have incorporated had I seen this first! The one I designed and built (my first), ended up MUCH heavier than I had hoped so it isn't exactly a "tractor" even though that was the intent.
  2. TNDadx4
    Thank you all for your comments. I appreciate them!
    Katoranger, yes, both the tractor and the hardware cloth have held up very well, although we recently replaced it with a hen house and yard.
  3. katoranger
    My tractor is twice the size, but I also have a tractor to move it with. I do like the idea of the hardware cloth on the bottom. Has it held up well?
  4. mxmarg
    Bless you TNDad for posting this! I'm about to embark on my own chicken tractor journey and this will be a HUGE help! Thanks for your ideas too David64!
  5. David64
    I think your coop is great. Your ideas for improvement would help too. I am thinking of building something similar. Except for the base, I think most of it could be constructed with 2x2's and 1x2's to reduce weight. In addition to the changes you suggested, I would make the coop a full four feet high. On the roost side, I would make the entire side an access door for cleaning. Larger wheels and a wooden trailer type tongue would help a lot in moving it.
