pictures of new homemade incubator. Any tips? advice?

Discussion in 'Incubating & Hatching Eggs' started by bigtime400, Mar 16, 2011.

  1. bigtime400

    bigtime400 Out Of The Brooder

    89
    0
    39
    Mar 8, 2011
    Beloit
    Here is my incubator. It has been holding temp fairy good. For the most part I have just been adjustiing the dimmer switch on the back and the thermostat hasnt turned on the light at all unless I have opened it up. I was thinking about moving the stat over by the light and the fan so it has more air flowing over those coils. The error factor on the stat was +/- 3.5 F . A little too much I think but I think that could be reduced by having the air flow over the coil.
    A couple things. Do you think I need more vent holes? Is the one by the tray going to be an issue? I have some egg cartons to put in the tray.

    Another thing I was worried about was room for the chicks after they hatch. The tray is removeable easily. Just unscrew those 2 screws on top pull the rod and lift it out.

    Hindsight there are a few things I would have done diffrently.....but my plans changed a few times due to the fact that I tried to use parts that I already had, changing ideas, and things that flat out didnt work.

    THe fan was nice. it was $6 at Menards and its a usb plug in just like your phone....so no need for a transformer and it pushes air better then a computer fan I think. The only reason I bought that was becasue I couldnt find the fan I tore out of my old comp.

    I am thinking about moving the stat right above the mason jar with water...... does that sound good?


    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG][/img]

  2. rebelcowboysnb

    rebelcowboysnb Confederate Money Farm Premium Member

    I would put the thermostat where the coils are by that light an over the fan.
    Vents should be fine. I have 2 holes the size of a quarter in my incubator that holds 11 dozen eggs.

  3. Cynthia12

    Cynthia12 Always Grateful Premium Member

    30,739
    5,691
    596
    Apr 11, 2010
    Utah
    bigtime..you're a genius! My husband wants to make me one really bad. He says something like this would be so much better than the Hovas that I use...
    question..does that tray move back and forth..to move the eggs, instead of you? I don't use trays, I move them myself. I'm afraid the trays put them too close to the heater rods, especially in the one without air..I do have the air bators, much better than no air.
    This looks great.

  4. PeckingOrder

    PeckingOrder Out Of The Brooder

    30
    0
    22
    Mar 14, 2011
    Only 1 suggestion, and that'd be to make the on/off button smaller so it can't get knocked which I've read more and more people doing lately.

    Other than that, looking good [​IMG]
